Tomi single Shaft Shredder is suitable for processing: non-ferrous metals, copper cables, aluminum cables, power coils, plastic bins, containers, composite materials, wood, paper, cardboard, industrial packaging, tires
Motor Power (kw): 3
Weight(KG): 300
Weight (kg): 100-300
Small single shaft shredder is mainly composed of a blade spindle, a fixed blade, a load-bearing box, a box support, a feeding system, a hydraulic pushing system, a power system, and an electrical control system. Mainly used for shredding waste materials such as wood, rubber, plastic, paper, etc.
The characteristics of this series single shaft shredding machine are slow speed of revolution, high pulling torque and low noise, etc. The screen can be customized according to customer needs.
Tomi single Shaft Shredder is suitable for processing: non-ferrous metals, copper cables, aluminum cables, power coils, plastic bins, containers, composite materials, wood, paper, cardboard, industrial packaging, tires, scraps, radiators with the presence of light ferrous parts and more.
Nichteisenmetalle
Kunststoffe
Kabel
Holz
Zusammengesetzte Materialien
Hausmüll
Utilizes a modular mortise and tenon structure with dual Hardox 450/Q690D steel-lined cavities, boosting space efficiency by 40%.
Siemens PLC real-time monitoring ensures safety against overload, temperature spikes, and pressure surges.
Schneider touchscreen supports one-touch programming with visualized current, temperature, and cycle data.
|
Modell |
SD-D350-1 |
|
Moving knife size |
35*35 |
|
Number of cuts |
7 |
|
Number of fixed knives |
1 |
|
Tool material |
D2 |
|
Feed port size（mm） |
750*525 |
|
Height of feed port from ground |
1100 |
|
Discharge port （mm） |
430*280 |
|
Voltage/Power |
220V/380V/50Hz/60Hz |
|
Dimensions（mm） |
L1145*W7600*H430 |
|
Weight（KG） |
300 |
|
Capacity（KG） |
100-300 |
